IKELITE UNDERWATER HOUSING 200DL FOR CANON EOS 90D

Capture sharp, detailed images at depths as great as 200' beneath the surface with your IKELITE UNDERWATER HOUSING 200DL FOR CANON EOS 90D. An Ikelite ICS-5 bulkhead with a manual hot shoe connection enables reliable electrical triggering of optional, external strobes. Use of an optional TTL hot shoe and circuitry will allow for TTL operation with compatible Ikelite DS strobes; non-Ikelite strobes will still work in manual mode only.

SPECIFICATIONS:

• 200' (60m) depth rating
• Compatible with DL system lens ports
• Controls are provided for all camera functions except Diopter adjustment, Control wheel lock, LCD illuminating button, Flash button, Joystick up/down/left/right (Joystick can be depressed)
• 1/4-20 thread base mounts with 3.5" spacing
• Slightly positive buoyancy in freshwater
• Actual buoyancy varies depending on the choice of lens and port
• Housing 4.67 lb (2121 g)
• Tray with left handle 11 oz (312 g)
• 9 x 7 x 6.5" (229 x 178 x 165 mm)

Construction Details

• Made by hand in the USA from corrosion-resistant polycarbonate and ABS plastic blend
• White on the front, top, sides, and bottom to reflect sunlight and keep the camera cool when shooting on or above water's surface
• Clear acrylic back, which is also corrosion-resistant, allows you to monitor the O-ring seal and maintain a view of the camera's rear controls
• Housing alone has nearly neutral buoyancy in fresh water; overall system buoyancy varies based on the choice of lens and port
• Open-groove design suspends rear O-ring in a natural position, allowing for easier maintenance and preventing accidental twisting or stretching of O-ring
• Front-loading camera mounting system makes installation and removal easy
• The camera mounting plate enables quick installation and does not need to be removed in order for you to gain battery or memory card access

Strobe Connection and Operation

• Ikelite ICS-5 bulkhead with manual hot shoe connection enables reliable electrical triggering of optional, external strobes via sync cords
• Optional CT2K Canon TTL Kit 46072 will allow for TTL operation with compatible Ikelite DS strobes; non-Ikelite strobes, such as Sea&Sea, Inon, and Nikonos models, will still work in manual mode only
• TTL exposure compensation adjustable in-camera

Controls and Handling

• Ergonomic mechanical controls, including push-buttons, knurled knobs/dials, and levers
• Controls afford access to many camera functions
• Following functions inaccessible: Diopter adjustment, control wheel lock, LCD illuminating button, flash button, joystick up/down/left/right (joystick can be depressed)
• Control symbols laser-etched into the rear of the housing won't fade with time
• Supplied anodized aluminum tray with a left-hand quick-release grip affords improved balance and handling while offering an attachment point for an optional lighting arm
• The camera mounting plate has a 1/4"-20 threaded hole for connection to optional tripod

Lens Port System

• Dry Lock (DL) Port System accommodates lenses with very large diameters
• Housing ships without a required lens port, and accepts interchangeable dome and flat ports for various zoom, macro, and wide-angle lenses
• Accepts an array of zoom and focus gears for various lenses
• The large, soft-touch knob on side of the housing makes small adjustments easy
• Provides added security against leaks at the surface, thanks in large part to included vacuum valve for checking watertight integrity before dive
• #47011 Pump with Gauge required in order to remove excess air and actually create a vacuum
